  9. Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 133 mm x 90 mm
Fluke Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 133 mm x 90 mm FLUKE-MDA-550/FPC - main

Handheld Oscilloscope, 500 MHz MHz, 4 Channels, 133 mm x 90 mm

  • Mfr # FLUKE-MDA-550/FPC

  • Zoro # G907630697

product price: $11,153.99
/ea
Free Shipping & Returns

Key Features

Bandwidth (MHz)
500 MHz
Channels
4
Display
133 mm x 90 mm
Interface
USB
Battery Type
Li-Ion
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FLUKE-MDA-550/FPC
Zoro #
G907630697
UPC #
754082155300
Country of Origin
Romania

Dimensions

Bandwidth (MHz)
500 MHz
Display Screen Length
5.2 in
Display Screen Width
3.5 in
Bandwidth
500 MHz

Details

Item
Handheld Oscilloscope
Channels
4
Display
133 mm x 90 mm
Interface
USB
Battery Type
Li-Ion
Triggering Mode
Auto
Safety Rating
CAT III 1000V / CAT IV 600V
Features
Built-In Report Writing Capabilities, Guided Testing with Graphical Step-By-Step Connection Diagrams, Preset Measurement Profiles
Waveform / Measurement Stored
10 Recording
Includes
(2) Extension Rod and Magnetic Base, (3) Brushes, (3) I400S AC Current Clamps, (3) VPS421 100:1 High Voltage Probes with Alligator Clips, AC Power Adapter, Carrying Case, MDA-550, Probe Holder, SVS-500 Shaft Voltage Set, VPS410-II-R 10:1 500MHz Voltage Probe, Wi-Fi Dongle
Battery Pack Recharge Time (Hr.)
5 hr
Battery Life
7 hr
True RMS
Yes
Standards
IEC 61010-1
Input Sensitivity - Minimum
100 V/div
Battery Chemistry
Lithium Ion
AC Magnitude Calculation
True RMS
CAT Safety Rating
CAT III 1000V, CAT IV 600V
Battery Run Time
7 hr
AC Voltage Measurement - Minimum
1 mV AC
AC Voltage Measurement - Maximum
1,000 V AC
Includes Batteries
Batteries Included
DC Current Measurement - Minimum
0.1 mA
Body Style
Handheld
AC Current Measurement - Minimum
0.1 mA
Calibration Certificate Type
Not Certified
AC Current Measurement - Maximum
400 mA
DC Current Measurement - Maximum
400 mA
Number of Batteries Required
1
AC Voltage Measurement Resolution
1 mV
DC Voltage Measurement - Minimum
1 mV DC
Power Source
AC Adapter, Battery
Number of Channels
4
DC Voltage Measurement - Maximum
1,000 V DC
Digital Display Screen Type
LCD

Description

Handheld Oscilloscope, Bandwidth (MHz) 500 MHz, 4 Channels, 133 mm x 90 mm Display, True RMS Yes, Sampling Rate Not Applicable, 10 Recording Waveform / Measurement Stored, Auto Triggering Mode, USB Interface, Safety Rating CAT III 1000V / CAT IV 600V, Li-Ion Battery Type, Battery Life 7 hr, Battery Pack Recharge Time (Hr.) 5 hr, Features Built-In Report Writing Capabilities, Guided Testing with Graphical Step-By-Step Connection Diagrams, Preset Measurement Profiles

Restrictions

Hazardous material
