Fluke Pressure Calibrator, -12 to 30 psi Fluke-718 30 - main

Pressure Calibrator, -12 to 30 psi

  • Mfr # Fluke-718 30

  • Zoro # G7819332

product price: $3,908.99
/ea
Free Shipping & Returns

Key Features

Includes
AC175 Alligator Clips, TL75 Test Leads
Display
Multiline LCD
Standards
ANSI/NEDA 1604A or IEC 6LR61, EN50082-1:1992 and EN55022:1994 Class B
Loop Supply Voltage
24 V DC
Powered By
(2) 9V Alkaline Batteries
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
Fluke-718 30
Zoro #
G7819332
UPC #
095969062084
Country of Origin
China

Dimensions

Manufacturers Warranty Length
3 yr
Battery Size
9V

Details

Item
Handheld Pressure Calibrator
Includes
AC175 Alligator Clips, TL75 Test Leads
Display
Multiline LCD
Standards
ANSI/NEDA 1604A or IEC 6LR61, EN50082-1:1992 and EN55022:1994 Class B
Loop Supply Voltage
24 V DC
Powered By
(2) 9V Alkaline Batteries
Current Measurement Range
0 to 24mA DC
Displayed Pressure Units
bar, cm wc, in Hg, in wc, kg/sq cm, kPa, mbar, mm Hg, psi
Measurement Functions
mA DC, Pressure
Internal Pressure Range Accuracy
+/-0.05% Full Scale
Internally Generated Pressure Range
0 to 30 psi
Internal Pressure Measurement Range
-12 to 30 psi
Calibration Certificate
NIST
Pressure Modules
750P Series (50 Ranges)
Pressure Source
Internal Electric Pump
Pressure Range with External Modules
1 in wc to 10,000 psi
Number of Batteries Required
2
Source Current - Minimum
0 mA
Pressure Measurement - Maximum
30 psi
Calibration Certificate Type
NIST
Parameters Sourced
AC Current, DC Current, Pressure
Intrinsic Safety
Not Specified Intrinsically Safe
Pressure Measuring Units
psi
Battery Chemistry
Alkaline
Digital Display Screen Type
LCD
Includes Batteries
Batteries Included
Current Measurement - Minimum
0 mA
Pressure Measurement - Minimum
-12 psi
Voltage Measurement - Minimum
0 V DC
Voltage Measurement - Maximum
30 V DC
Pressure Measurement Accuracy
+/-0.025% Full Scale
Current Measurement - Maximum
24 mA
Parameters Measured
AC Current, DC Current, Pressure
Source Current - Maximum
24 mA

Description

Handheld Pressure Calibrator, Internal Electric Pump Pressure Source, Measurement Functions mA DC, Pressure, Internal Pressure Measurement Range -12 to 30 psi, Internally Generated Pressure Range 0 to 30 psi, Pressure Range with External Modules 1 in wc to 10,000 psi, Loop Supply Voltage 24 V DC, Current Measurement Range 0 to 24mA DC, Display Multiline LCD, Standards ANSI/NEDA 1604A or IEC 6LR61, EN50082-1:1992 and EN55022:1994 Class B, Calibration Certificate NIST
