This item is Discontinued.

Fostoria Electric Infrared Heater, Ceiling, Suspended, Aluminum, 10,748 BtuH FSS-3148-1

Electric Infrared Heater, Ceiling, Suspended, Aluminum, 10,748 BtuH (Discontinued)

  • Mfr # FSS-3148-1
  • Zoro # G0459700
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
FSS-3148-1
Zoro #
G0459700
UPC #
686334488242
Country of Origin
United States

Dimensions

Length
46"
Width
9"
Height
8-1/2"
Overall Width
9 in
Overall Length
46 in
Grille Depth
1/8 in
Grille Width
9 in
Overall Depth
8 1/2 in
Grille Height
46 in
Overall Dimensions - L x W x D
46 in x 9 in x 8-1/2 in

Details

Indoor/Outdoor Usage
Indoor/Outdoor
Electric Heater Item
Electric Infrared Heater
Heater Mounting Type
Ceiling, Suspended
Includes
Electrical Enclosure, Grill, Top L-Bracket Supports
Watts
3150
BtuH Output
10,748
Item
Electric Infrared Heater
Heater Voltage
480VAC
Electric Heater Phase
1
Number of Lamps
1
Beam Pattern
60 Degrees
Watts Delivered/Sq.-Ft. 14
21
Watts Delivered/Sq.-Ft. 12
32.5
Heat Pattern Coverage @ Floor (8 Ft.)
9 x 8
Amps @ 1 Phase
6.56
Watts Delivered/Sq.-Ft. 8
62.5
Housing Material
Aluminum
Heat Pattern Coverage @ Floor (12 Ft.)
13 x 12
Heat Pattern Coverage @ Floor (10 Ft.)
11 x 10
Element Type
Flat Panel Emitter
Heat Pattern Coverage @ Floor (14 Ft.)
15 x 14
Radiant Efficiency
78.5 %
Watts Delivered/Sq.-Ft. 10
41
Infrared Electromagnetic Wave Type
Medium Wave
Standards
ETL Listed for US & Canada
Finish
Aluminum, Gold Anodized
Phase
1
Voltage
480V AC
NEMA Plug Configuration
Hardwired
Housing Color
Gold
Electrical Connection
Hardwired
Brightness
31 lm
Wattage Output
3150W
Max. Operating Temp.
Varies, based on distance from target & mounting height
Housing Finish
Gold Anodized
Amperage
6.6A
Heating Method
Radiant
Heating Capacity
10,748 BtuH
Mobility
Stationary
Heater Mounting Position
Horizontal or Vertical Burn
For Use Outdoors
Indoor/Outdoor
Frequency
50/60Hz
Voltage, Phase
480V AC, 1-phase
Reflector Material
Aluminum, Gold Anodized
Grille Material
Steel, Zinc Plated
Housing Material, Housing Color
Aluminum, Gold
For Use Indoors/Outdoors
Indoor/Outdoor

Description

Electric Infrared Heater, Overall Length 46 in, Overall Width 9 in, Overall Depth 8 1/2 in, Phase 1, Voltage 480V AC, Wattage Output 3150W, Beam Pattern 60 Degrees , Element Type Flat Panel Emitter, Housing Color Gold, Housing Material Aluminum, Mounting Type Suspended, Grille Depth 1/8 in, Grille Height 46 in, Grille Width 9 in, Grille Material Steel, Zinc Plated, Heating Capacity 10,748 BtuH, Heating Method Radiant, Housing Finish Gold Anodized, Electrical Connection Hardwired
