- MFR #
- WH5-277-L
- Zoro #
- G9123134
- UPC #
- 872180100814
- Country of Origin
- China
- Ballast Lamp Type
- Compact Fluorescent, 2D, T5, T5HO, T6, T8, T8HO, T9, T12, T12HO
- Item
- Fluorescent Ballast
- Ballast Max. Number of Lamps
- 4
- Input Voltage
- 277V AC
- Ballast Voltage
- 277
- Ballast Start Type
- Instant
- Ballast Dimming
- No
- Ballast Item
- Electronic Ballast
- Ballast Type
- Electronic
- Ballast Max. Lamp Watts
- 128
- Ballast Dimming Type
- No Dimming
- Input Watts
- 25 to 113 W
- Ballast Family
- WorkHorse
- Number of F18/19T8 Lamps
- 2, 3, or 4
- Wiring Type
- Parallel
- Number of F58T8 Lamps
- 2
- Number of F40T12 Lamps
- 1 or 2
- Number of F24/F36T12 Lamps
- 1 or 2
- Number of F60T12 Lamps
- 1
- Number of F24T5 Lamps
- 2, 3, or 4
- Number of F96T12 Lamps
- 1 or 2
- Min. Starting Temp.
- -22 Degrees F
- Number of F50BX Lamps
- 1 or 2
- Number of F72T12 Lamps
- 1 or 2
- Number of F15T8 Lamps
- 3 or 4
- Number of F32T8(26W) Lamps
- 3 or 4
- Number of F30T12 Lamps
- 1 or 2
- Amps AC
- 0.4 A
- Number of F34T12 Lamps
- 1 or 2
- Number of F60/F64T12 Lamps
- 1
- Number of F48T12 Lamps
- 1
- Number of F40BX Lamps
- 2 or 3
- Number of F32T8 Lamps
- 3 or 4
- Number of F64T12 Lamps
- 1
- Number of F25T8 Lamps
- 3 or 4
- Total Harmonic Distortion
- 35 %
- Light Output
- Normal
- Number of F42/F48T12 Lamps
- 1
- Number of F30T8 Lamps
- 2, 3, or 4
- Number of F32T8U Lamps
- 3 or 4
- Number of FC12T5 Lamps
- 2
- Power Factor
- Greater Than 0.98
- Ballast Lamp Watts
- 128
- Number of F40T12 U-Bend Lamps
- 1 or 2
- Number of F60/F64T12 Lamps
- 1 or 2
- Number of F42/F48T12 Lamps
- 1
- Number of F48T8 Lamps
- 1
- Number of F32T8(28W) Lamps
- 3 or 4
- Number of F28T8 Lamps
- 3 or 4
- Number of F20T12 Lamps
- 2, 3, or 4
- Number of F24/F36T12 Lamps
- 1 or 2
- Number of F39T5 Lamps
- 2 or 3
- Ballast Factor
- 1.15
- Number of F17T8 Lamps
- 3 or 4
- Number of F32T8(30W) Lamps
- 3 or 4
- Number of F13T8 Lamps
- 3 or 4
- Number of F60T8 Lamps
- 1
- Number of F54T5 Lamps
- 1 or 2
- Number of F25T12 Lamps
- 1 or 2
- Number of F55BX Lamps
- 1 or 2
- Voltage
- 277
- Standards
- ANSI C82.11-1993, FCC Part 18-A, UL Listed
- Fixture Ballast Type
- Electronic
- Ballast Bulb Type
- DBX, T12, T5-Circuline, T8
- Number of F84T12 Lamps
- 1 or 2
- Sockets Included
- No
- Dimming Type
- No Dimming
- Starter Required
- No
- Number of F14/15T8 Lamps
- 3 or 4
- Operating Amps @ 120V
- 0.43 A
- Dimming Method
- No Dimming
- Frequency
- 50/60 Hz
- Number of F14/15T12 Lamps
- 1 or 2
- Number of F14T12 Lamps
- 1 or 2
- Brand and Series
- WorkHorse
- Dimming Range
- No Dimming
- Number of F15T12 Lamps
- 2, 3, or 4
- Number of F42T12 Lamps
- 1
- Number of F13DBX Lamps
- 3 or 4
- Number of F36T12 Lamps
- 1
- Max. Bulb Watts
- 12 W, 13 W, 15 W, 17 W, 24 W, 25 W, 28 W, 32 W, 44 W, 45 W, 55 W, 58 W, 60 W, 75 W, 80 W, 85 W
- Number of Bulbs Supported
- 1, 2, 3, 4
- Thermal Protection
- Class P
- Dimming
- No
- Hz
- 50/60
- Lamp Types Supported
- (1 or 2) F24T12, (1 or 2) F25T12, (1 or 2) F36T12, (1 or 2) F96T12, (1) F36T12, (1) F42T12, (1) F48T8, (1) F60T12, (1) F60T8, (1) F64T12, (2) F58T8, (2) FC12T5, (3 or 4) F13DBX, (3 or 4) F15T8, (3 or 4) F17T8, (3 or 4) F25T8, (3 or 4) F28T8, (3 or 4) F32T8
