  11. Class 2 Transformer, 40 VA, NEMA 1, 24V AC, 120/240/277/347/480V AC
Functional Devices-Rib Class 2 Transformer, 40 VA, NEMA 1, 24V AC, 120/240/277/347/480V AC PSH200A - main

Class 2 Transformer, 40 VA, NEMA 1, 24V AC, 120/240/277/347/480V AC

  • Mfr # PSH200A

  • Zoro # G6554563

product price: $575.99
/ea
Free Shipping & Returns

Key Features

Input Voltage - Transformer
120/240/277/347/480V AC
Output Voltage
24V AC
Power Rating
40 VA
Phase
1
Mounting - Transformer
Wall
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PSH200A
Zoro #
G6554563
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
4 1/2 in
Overall Width
5.44 in
Overall Depth
4 1/2 in
Circuit Breaker Size
10 A

Details

Item
Class 2 Transformer
Input Voltage - Transformer
120/240/277/347/480V AC
Output Voltage
24V AC
Power Rating
40 VA
Phase
1
Mounting - Transformer
Wall
Hz - Electrical
50/60 Hz
NEMA Enclosure Rating
NEMA 1
Enclosure Type
Enclosed
Secondary Connection
Screw Terminals
Standards
CE, RoHS, UL Class 2, UL Listed
Protective Device
Circuit Breaker
Enclosure Finish
Powder Coated
Includes
10A Main Breaker Switch, 120V AC Convenience Outlets, Finger-Safe Terminals, LED Power Indicator, On/Off Control
Enclosure Style - Transformer
Enclosed
Primary Connection
Screw Terminals
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
24 Vac ON/OFF
On / Off Switch & Breaker
Output
5 Ungrounded, Isolated, 40 VA, Class 2, 24 Vac Outputs. Terminals accept 12-26 AWG wire
Sub-Panel
NEMA1 Metal Enclosure (PSH200A)
Secondary Output Voltage vs. Load
24.9 V @ 0.5 Amp 24.0 V @ 1.0 Amp 23.9 V @ 1.4 Amp 23.7 V @ 1.6 Amp
Full Load Primary Current
2.57 A @ 120 Vac 1.44 A @ 240 Vac 1.17 A @ 277 Vac 0.95 A @ 347 Vac 0.73 A @ 480 Vac
Standby Wattage
18.93 W @ 120 Vac 22.08 W @ 240 Vac 22.33 W @ 277 Vac 23.11 W @ 347 Vac 25.24 W @ 480 Vac
Transformer
One (1) 200 VA
5 Secondaries
24 Vac, with LED Indicators
Ambient Temperature Derating
1.6A up to 40°C ; 1.2A up to 60° C
Approvals
Class 2 (UL Approved UL5085-3),
Number of Outputs
2
Overcurrent Protection
Circuit Breaker
Operating Temperature - Maximum
60 Degrees C
Number of Convenience Outlets
1
Housing Material
Metal
Includes On/Off Switch
Individual Output On/Off Switch
Wire Connection Type
Screw Terminals
Temperature Rise
Not Rated

Description

Class 2 Transformer, (5) 40 VA Rating, Input Voltage 120/240/277/347/480VAC, Output Voltage 24VAC, Multi Mounting, Protective Device Circuit Breaker, Primary Connection Screw Terminals, Secondary Connection Screw Terminals, 1 Phase, 50/60 Hz, Not Rated Temp. Rise, Enclosed Enclosure Type, Enclosure Rating NEMA 1, Enclosure Finish Powder Coated, Height 4.50 In., Depth 4.50 In., Width 5.44 In.
