55 Degree Milling Insert for Internal/External Thread, 11 TPI
Mfr # 218080 11
Zoro # G316115570
product price:Â $131.99
/ea
Free Shipping & Returns
Key Features
Insert Material
Carbide
Grade
HB7720
Insert Size
25 mm
Cutting Direction
right-hand and left-hand
Coating
TiAlN
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- 218080 11
- Zoro #
- G316115570
- UPC #
- -
- Country of Origin
- Israel
Dimensions
- Insert Size
- 25 mm
Details
- Item
- Cutter insert for milling
- Insert Material
- Carbide
- Grade
- HB7720
- Cutting Direction
- right-hand and left-hand
- Coating
- TiAlN
- Flank Angle
- 55°
- Thread Pitch
- 2,309 mm
- Teeth per Inch
- 11
- Thread per Inch
- 11
- Correction Factor
- 2.5
- Full Profile
- Yes
- Thread profile
- Full profile
- Number of Teeth
- 10
Description
Version: Sturdy milling inserts for high feed rates and high productivity. Double-edged. Application: For internal and external threads 55 deg. to standard BS 84: 1956- DIN 259- ISO 228/1: 1982. Tolerance class Medium Class A. Note: Always fit the thread milling inserts with the marks matching- otherwise the thread will be distorted! Sides have either a mark or no mark. Feed fz = HB 7720 in steel 900 N/mm2 = 0.15 mm / tooth. Insert size: 25 mm
