55 Degree Milling Insert for Internal/External Thread, 11 TPI
Mfr # 218081 11
Zoro # G716115637
product price: $131.99
/ea
Free Shipping & Returns
Key Features
Coating
TiAlN
Cutting Direction
right-hand and left-hand
Insert Material
Carbide
Insert Size
25 mm
Grade
HB7735
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
218081 11
Zoro #
G716115637
UPC #
-
Country of Origin
Israel
Dimensions
Insert Size
25 mm
Details
Item
Cutter insert for milling
Coating
TiAlN
Cutting Direction
right-hand and left-hand
Insert Material
Carbide
Grade
HB7735
Number of Teeth
10
Thread per Inch
11
Full Profile
Yes
Thread Pitch
2,309 mm
Teeth per Inch
11
Correction Factor
2.5
Flank Angle
55°
Thread profile
Full profile
Description
Version: Sturdy milling inserts for high feed rates and high productivity. Double-edged. Application: For internal and external threads 55 deg. to standard BS 84: 1956- DIN 259- ISO 228/1: 1982. Tolerance class Medium Class A. Note: Always fit the thread milling inserts with the marks matching- otherwise the thread will be distorted! Sides have either a mark or no mark. Feed fz = HB 7720 in steel 900 N/mm2 = 0.15 mm / tooth. Insert size: 25 mm
