Carbide Turning Insert, Diamond, CCMT32.51 / CCMT09T304, for Stainless Steel
Mfr # 260058 HB7140-2
Zoro # G814822826
product price:Â $10.35
/ea
Sold in multiples of 10 for $103.50
Key Features
ISO Number
CCMT 09T304
No. of Edges
2
Min. Cutting Depth (ap min)
0.25 mm
Insert Shape
80 Degrees Diamond
Grade
HB7140-2
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
260058 HB7140-2
Zoro #
G814822826
UPC #
-
Country of Origin
Japan
Dimensions
Min. Cutting Depth (ap min)
0.25 mm
Insert Thickness
2.5 mm
Corner Radius
0.4 mm
Cutting Depth
0.2 mm
Max. Cutting Depth (ap max)
3.25 mm
Details
ISO Number
CCMT 09T304
No. of Edges
2
Item
Indexable Insert for Turning
Insert Shape
80 Degrees Diamond
Grade
HB7140-2
Coating
coated
Workpiece Material
Stainless Steel
Tolerance
Stainless Steel
Insert Application
Finishing
Insert Material
Carbide
Insert Style
CCMT
Inscribed Circle
3
Cutting Conditions
Heavily Interrupted
Chip-Breaker
VS
Description
CC.T 09T304 HB7140-2 Grade: HB7140-2 Chip breaker: VS Tolerance: M Cutting depth ap: 0.2 2.5 mm Feed f: 0.1 0.3 mm/rev. Cutting speed vc main application: 70 230 m/min
