Carbide Turning Insert, Parallelogram, ZCMX050204, for Steel
Mfr # 268420 HBZ025
Zoro # G514822720
product price: $17.45
/eaSold in multiples of 10 for $174.50
Key Features
Insert Style
ZCMX
Insert Shape
Parallelogram
Coating
PVD
Corner Radius
0.4 mm
Insert Size
50204
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268420 HBZ025
Zoro #
G514822720
UPC #
-
Country of Origin
Austria
Dimensions
Corner Radius
0.4 mm
Insert Size
50204
Suitable Tool Diameter
10 mm
Max. Cutting Depth (ap max)
1.75 mm
Min. Cutting Depth (ap min)
0.25 mm
Insert Thickness
1.5 mm
Cutting Depth
0.4 mm
Details
Insert Style
ZCMX
Insert Shape
Parallelogram
Coating
PVD
Item
Indexable Insert for Turning
Inscribed Circle
5 mm
ISO Number
ZCMX 050204
Cutting Conditions
Continuous
No. of Edges
2
Grade
HBZ025
Workpiece Material
Steel
Insert Material
Carbide
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. suitable for tool dia. Dc: 10 mm Grade: HBZ025 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 90 210 m/min
