Carbide Turning Insert, Parallelogram, ZCMX09T304, for Stainless Steel
Mfr # 268438 HBZ140
Zoro # G714821721
product price: $18.29
/ea
Sold in multiples of 10 for $182.90
Key Features
Insert Size
09T304
Inscribed Circle
9 mm
Corner Radius
0.4 mm
Cutting Depth
0.4 mm
No. of Edges
2
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
268438 HBZ140
Zoro #
G714821721
UPC #
-
Country of Origin
Austria
Dimensions
Insert Size
09T304
Corner Radius
0.4 mm
Cutting Depth
0.4 mm
Min. Cutting Depth (ap min)
0.55 mm
Suitable Tool Diameter
18 mm
Insert Thickness
2.5 mm
Max. Cutting Depth (ap max)
3.5 mm
Details
Inscribed Circle
9 mm
No. of Edges
2
Cutting Conditions
Slightly Interrupted
Workpiece Material
Stainless Steel
Insert Material
Carbide
Grade
HBZ140
Item
Indexable Insert for Turning
Insert Style
ZCMX
ISO Number
ZCMX 09T304
Coating
PVD
Insert Shape
Parallelogram
Description
General-purpose medium grit substrate with PVD coating. First choice for turning and drilling applications. Suitable for: Boring tool No. 268463 268468, size 8. suitable for tool dia. Dc: 18 mm Grade: HBZ140 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 50 190 m/min
