Carbide Turning Insert, Parallelogram, ZCMX130408, for Steel
Mfr # 268444 HBZ030
Zoro # G314822944
product price:Â
$
20.19
/ea
Sold in multiples of 10 for $201.90
Key Features
Insert Shape
Parallelogram
Insert Style
ZCMX
Inscribed Circle
13 mm
Insert Size
130408
Grade
HBZ030
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 268444 HBZ030
- Zoro #
- G314822944
- UPC #
- -
- Country of Origin
- Austria
Dimensions
- Insert Size
- 130408
- Corner Radius
- 0.8 mm
- Suitable Tool Diameter
- 25 mm
- Insert Thickness
- 3 mm
- Max. Cutting Depth (ap max)
- 2.75 mm
- Min. Cutting Depth (ap min)
- 0.55 mm
- Cutting Depth
- 0.4 mm
Details
- Item
- Indexable Insert for Turning
- Insert Shape
- Parallelogram
- Insert Style
- ZCMX
- Inscribed Circle
- 13 mm
- Grade
- HBZ030
- Insert Material
- Carbide
- ISO Number
- ZCMX 130408
- Coating
- CVD
- No. of Edges
- 2
- Workpiece Material
- Steel
- Cutting Conditions
- Continuous
Description
Harder substrate for longer tool life with thinner CVD coating. Especially for facing and longitudinal turning applications. suitable for tool dia. Dc: 25 mm Grade: HBZ030 Cutting depth ap: 0.4 2 mm Feed rate f when turning: 0.1 0.3 mm Feed rate f when drilling: 0.03 0.12 mm Cutting speed vc main application: 70 200 m/min
