Power Tang Square Tangential Shoulder Mill, with Bore, 100mm Diameter, 9 Effective Inserts
Mfr # 215122 100/9
Zoro # G016121048
product price: $1,074.99
/ea
Free Shipping & Returns
Key Features
Insert Screw
219882 (15IP; 3.0 Nm)
Cutting Dia.
100 mm
Overall Length
50 mm
Cutting Angle
90°
Series
Power Tang
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
215122 100/9
Zoro #
G016121048
UPC #
-
Country of Origin
Sweden
Dimensions
Cutting Dia.
100 mm
Overall Length
50 mm
Free length
50 mm
Mounting Bore Dia.
32 mm
Max. Cutting Depth
12 mm
Details
Insert Screw
219882 (15IP; 3.0 Nm)
Item
End / face mill
Cutting Angle
90°
Series
Power Tang
Number of Teeth
9
Tool Exchange
PowerCard
Milling Application
Corner milling
Coolant Through
Yes
Effective Dia/Overhang
100 mm/9 mm
Shank Type
with bore
Description
Version: Maximum stability due to tangentially arranged inserts. High feed rate values for maximum metal removal rate due to optimum indexable insert with stability in the direction of the cutting force. Note: Use GARANT torque screwdriver TQ No. 211750 size 3.0 with bit No. 674252 size 15IP. Tool exchange: PowerCard maximum cutting depth ap max: 12 mm Overall length Ltot: 50 mm Mounting bore : 32 mm suitable indexable insert: LO.. 130708 Pack of insert screws: 219882 15IP- 3.0 Nm
