Molded Case Circuit Breaker, THQL Series, 30A, 2 Pole, 120/240V AC, 10kA at 120/240V AC
Mfr # THQL2130
Zoro # G1144464
CAD Available
product price: $22.25
/eaKey Features
CAD Drawing
Series
THQL
Number of Poles
2
AC Voltage Rating
120/240V AC
Circuit Breaker Type
Standard
Phase
1
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
THQL2130
Zoro #
G1144464
UPC #
783164012927
Country of Origin
Dominican Republic
Dimensions
Frame Size
100A/THQ
Width
2 in
Depth
2-3/8 in
Height
3-9/32 in
Max. Wire Size
8 AWG
Min. Wire Size
14 AWG
Length
3.28 in
Description
Miniature Circuit Breaker, Amps 30 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series AQ, Phase Single, Series THQL, Max. AIR Rating 10kA at 120/240V AC, For Use With Power Mark Gold Load Centers and AQ Lighting Panels, Terminal Connection Screw Clamp, Frame Size 100A/THQ, Length 3.28 in, Width 2 in, Depth 2.38 in
