  9. Cable, Cat 6, 23 AWG, 1000 ft, Gray
Shop All Data & Ethernet Cables
Genspeed

Cable, Cat 6, 23 AWG, 1000 ft, Gray

original price: $679.99
8% off
new price: $620.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Category - Data Cable 6
  • Fire Rating - Data Cable Riser
  • Standards ANSI/TIA/EIA 568-B.2-1, ANSI/TIA/EIA 862, ICEA S-102-700, ISO/IEC 11801 Ed. 2.0 (Class E), NEC/CEC Type CMP (NFPA 262), NEC/CEC Type CMR (UL 1666), UL 444
  • Shielded Unshielded
  • Jacket Color Gray
See all product information

Product Information

Dimensions

Spool Length 1,000 ft
Conductor Size - Data Cable 23 AWG
Cable Length 1,000 ft
Outside Dia. 0.215 in
Bend Radius 1 in
Length 1000 ft.
Wire Size 23 AWG
Outside Diameter 1/4 in

Details

Item - Data Cable Category Cable
Category - Data Cable 6
Fire Rating - Data Cable Riser
Standards ANSI/TIA/EIA 568-B.2-1, ANSI/TIA/EIA 862, ICEA S-102-700, ISO/IEC 11801 Ed. 2.0 (Class E), NEC/CEC Type CMP (NFPA 262), NEC/CEC Type CMR (UL 1666), UL 444
Shielded Unshielded
Jacket Color Gray
Package Type - Data Cable Pulling Pack
Item Category Cable
Total Number of Conductors - Data Cable 8 (4 Pair)
Package Type Pulling Pack
Jacket Material PVC
Category Type 6
Number of Conductor Pairs 4
Shielded / Unshielded Unshielded
Solid / Stranded Solid
NEC Article and Type 800 CMR
Frequency 350 MHz
Operating Temp. Range -10 Degrees to 60 Degrees C
Plenum Rated Yes
Pulling Force 32 lb
Installation Temp. Range 0 Degrees to 60 Degrees C
Jacket Material - Wire and Cable PVC
Number of Conductors 8
Maximum Frequency 350 MHz
Performance Category 6
Fire Rating Riser
Maximum Operating Temperature 140 Degrees F
Solid/Stranded Solid
Number of Pairs 4
Minimum Operating Temperature 14 Degrees F
Conductor Gauge 23 AWG

Description

Category Cable, Cable Length 1,000 ft, Conductor Gauge 23 AWG, Fire Rating Riser, Jacket Color Gray, Jacket Material PVC, Outside Diameter 1/4 in, Performance Category 6, Shielded Unshielded, Number of Conductors 8, Number of Pairs 4, NEC Article and Type 800 CMR, Standards ANSI/TIA/EIA 568-B.2-1, ANSI/TIA/EIA 862, ICEA S-102-700, ISO/IEC 11801 Ed. 2.0 (Class E), NEC/CEC Type CMP (NFPA 262), NEC/CEC Type CMR (UL 1666), UL 444, Package Type Pulling Pack, Solid/Stranded Solid, Bend Radius 1 in
