Gf Piping Systems

1" FNPT Polypropylene Ball Valve Inline True Union

product price: $160.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Body Material Polypropylene
  • Body Style Inline True Union
  • Handle Type Tee
  • Ball Valve Product Group Manual
  • Stem Type Blowout Proof
See all product information

Product Information

Dimensions

Pipe Size 1"
Overall Length 4.16 in
Nominal Valve Size 1 in
Connection Size - Side 1 1 in
Handle Height 3.15 in
Connection Size - Side 2 1 in
Handle Length 2.44 in

Details

Body Material Polypropylene
Body Style Inline True Union
Handle Type Tee
Ball Valve Product Group Manual
Stem Type Blowout Proof
Standards ASTM D 4101
Max. Pressure 150 psi CWP
Connection Type FNPT x FNPT
Item Ball Valve
Ball Valve Basic Body Material Plastic
Body Seal Material EPDM
Stem Material Polypropylene
Temp. Range 32 Degrees to 176 Degrees F
Port Full
Features Integrated Stainless Steel Mounting Inserts
Valve Structure 2-Piece
Handle Material Glass Filled Polypropylene
Seat Material PTFE
Ball Material Polypropylene
Max. Steam Pressure 75 psi WSP
Seal Material PTFE
Connection Socket/Threaded
Type Two Piece, True Union, Actuatable
Special Features Actuator Compatible
Material of Construction Polypropylene
Sub-Category Synthetic Ball Valves
Connection Gender - Side 2 Female
For Media Corrosive Chemicals, Water
Ball Port Style Full Port
Color - Valve Handle Orange
Maximum Pressure - Combustible Gas Not Rated
3-A Standard Compliance Not Rated
Valve Body Style Straight
Included Mounting Base Pad
Connection Gender - Side 1 Female
Operating Temperature - Maximum 176 Degrees F
Valve Ways 2-Way
Valve Construction Two-Piece
Operating Temperature - Minimum 32 Degrees F
Connection Type - Side 2 NPT
Coefficient of Volume (Cv) 49
Maximum Pressure - Operating 10 bar
Connection Type - Side 1 NPT
NSF Certifications for Food and Drinking Water NSF 61

Description

Manual Two-Way Ball Valve, Body Material Polypropylene, For Media Corrosive Chemicals, Water, Valve Construction Two-Piece, Nominal Valve Size 1 in, Valve Body Style Straight, 3-A Standard Compliance Not Rated, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 10 bar, Maximum Pressure - Steam Not Applicable, Maximum Pressure - Combustible Gas Not Rated, Vacuum Service Rating Not Applicable, Ball Material Polypropylene, Ball Port Style Full Port
