Ball Bearing Supported Clutches
- Mfr # FND 437-M
- Zoro # G516498299
product price:Â
$
833.99
/ea
Free Shipping & Returns
Key Features
Keyway Width
5 mm
Frequency
60 Hz
Static Torque
129.8 ft-lb
Keyway Depth
2 3/10 mm
Overall Width
34 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- FND 437-M
- Zoro #
- G516498299
- UPC #
- -
- Country of Origin
- Germany
Dimensions
- Keyway Width
- 5 mm
- Keyway Depth
- 2 3/10 mm
- Overall Width
- 34 mm
- Outside Diameter
- 41 mm
- Shaft Diameter
- 15 mm
Details
- Item
- Ball Bearing Supported Clutches
- Frequency
- 60 Hz
- Static Torque
- 129.8 ft-lb
- Maximum Ambient Temperature
- 110 Degrees C
- Application
- Backstops/Overrunning Clutches, Indexing Clutches
- Maximum Speed
- 1,700 RPM
- Standards
- DIN 6885
- Clutch/Brake Type
- Sprag
- Housing Material
- Steel
Description
Ball Bearing Supported Clutches, Clutch/Brake Type Sprag, Static Torque 129.8 ft-lb, Shaft Diameter 15 mm, Maximum Speed 1,700 RPM, Outside Diameter 41 mm, Overall Width 34 mm, Standards DIN 6885, Application Backstops/Overrunning Clutches, Indexing Clutches
