  6. Solenoid, Box Fram, 1/8 - 1 in, Intermittnt

This item is Discontinued.

Guardian Electric Solenoid, Box Fram, 1/8 - 1 in, Intermittnt 11-I-120A

Solenoid, Box Fram, 1/8 - 1 in, Intermittnt (Discontinued)

  • Mfr # 11-I-120A
  • Zoro # G1025482
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
11-I-120A
Zoro #
G1025482
UPC #
-
Country of Origin
United States

Dimensions

Depth
1 3/16 in
Length
1 13/16 in
Body Length
1 13/16 in
Width
15/16 in
Length (Straight Wireway)
1 13/16 in

Details

Item
Solenoid
Solenoid Type
Box Frame
Stroke Range
1/8 in to 1 in
Pull Force Range
8.0 to 24.0 oz
Terminals
Solder Lug
Coil Volts
120V AC
Duty Cycle
Intermittent
Coil Insulation
Class 105
Material of Construction
Steel
From Mounting Holes to Plunger Hole
7/16 in
Pull @ 3/4 In. Stroke
18.0 oz
Coil Resistance
85.0 ohm
Pull @ 1/2 In. Stroke
22.0 oz
Seated Watts
40 W
Mounting Holes
6-32 UNC -2B (4 Holes)
Pull @ 1 In. Stroke
18.0 oz
Seated Amps
85 mA
Pull @ 5/8 In. Stroke
20.0 oz
Pull @ 1/4 In. Stroke
24.0 oz
Standards
RoHs, UL
Pull @ 3/8 In. Stroke
22.0 oz
Pull @ 1/8 In. Stroke
24.0 oz

Description

Solenoid, Box Frame, Stroke Range 1/8 in to 1 in, Pull Force Range 8.0 to 24.0 oz, Width 15/16 in, Depth 1 3/16 in, Length 1 13/16 in, Body Length 1 13/16 in, Coil Volts 120V AC, Seated Amps 85 mA, Seated Watts 40 W, Coil Resistance 85.0 ohm, Coil Insulation Class 105, Terminals Solder Lug, Duty Cycle Intermittent, Material of Construction Steel, Mounting Holes 6-32 UNC -2B (4 Holes), 7/16 in From Mounting Holes to Plunger Hole, Standards RoHs, UL
