Solenoid, Tubulr, 1/8 - 3/4 in, Intermittnt

GUARDIAN ELECTRIC| Zoro #: G0586975| Mfr #: TP8X16-I-24D

$27.94 /ea

Orders over $50.00 ship free. DetailsStandard ground shipping

Technical Specifications

Zoro #: G0586975 Mfr #: TP8X16-I-24D
Mounting Holes: Mounting Bracket (2 Holes)Terminals: 6.5" Leads
Material of Construction: SteelStandards: UL, RoHs
Solenoid Type: TubularItem: Solenoid
Coil Insulation: Class 105Stroke Range: 1/8" to 3/4"
Pull @ 7/8 In. Stroke: 112.0 oz.Body Length: 2-1/32"
Pull @ 1/8 In. Stroke: 176.0 oz.Seated Watts: 16.8
Pull @ 1/4 In. Stroke: 144.0 oz.Seated Amps: 665mA
Pull @ 3/8 In. Stroke: 144.0 oz.Duty Cycle: Intermittent
Pull @ 1/2 In. Stroke: 145.6 oz.Length: 2-1/32"
Pull @ 5/8 In. Stroke: 145.6 oz.Dia.: 1"
Pull @ 1 In. Stroke: 92.8 oz.Coil Volts: 24VDC
Pull @ 3/4 In. Stroke: 134.4 oz.Coil Resistance: 36.1 ohm
Pull Force Range: 6.0 to 32.0 oz.Country of Origin (subject to change): United States

Product Description

Solenoid, Tubular, Dia. 1 In., Body Length 2 1/32 In., Length 2 1/32 In., Coil Volts 24DC, Seated Amps 665mA, Seated Watts 16.8, Coil Resistance (Ohms) 36.1, Coil Insulation Class 105, Terminals 6.5 In Leads, Duty Cycle Intermittent, Material of Construction Steel, Mounting Holes MOUNTING BRACING (2 HOLES), Standards UL, RoHs
