  13. Electric Chain Hoist, 250 lb cap.
Harrington Electric Chain Hoist, 250 lb cap. EM001S-10 - main

Electric Chain Hoist, 250 lb cap.

  • Mfr # EM001S-10

  • Zoro # G009833828

product price: $2,800.99
/ea
Free Shipping & Returns

Key Features

Color
Yellow
Phase
3
Standards
ASME, FEM, ISO, UL 1340/CSA 22.2
Voltage
230V AC
Number of Speeds
1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EM001S-10
Zoro #
G009833828
UPC #
-
Country of Origin
Japan

Dimensions

Chain Length
11 ft
Maximum Lifting Length
10 ft
Body Length
11 1/2 in
Body Depth
7 29/32 in
Lifting Hook Opening Width
1 13/32 in
Controller Cord Length
8 3/16 ft
Minimum Retracted Length
11 19/32 in
Mfr. Warranty Length
5 yr
Body Width
11 1/2 in

Details

Color
Yellow
Phase
3
Standards
ASME, FEM, ISO, UL 1340/CSA 22.2
Voltage
230V AC
Number of Speeds
1
Thermal Protection
Included
Item
Electric Chain Hoist
Includes Brake
Brake Included
Included Components
Chain Container, Pendant
Lifting Hook Type
Hook with Safety Latch
Controls
Push Button Pendant
Chain Grade
Grade 80
Maximum Lifting Capacity
250 lb
Current at Max. Voltage
1.4 A
Clutch Type
Friction Clutch
Mount Type
Hook Mounted - No Trolley
Duty Classification
H4
Lifting Hook Material
Steel
Body Material
Die-Cast Aluminum
Chain Material
Nickel Plated
Pendant IP Rating
IP65
Programmable
Non-Programmable
Motor Horsepower
3/8 hp
Features
Upper Limit Switch, Non-Drip, Grease Packed Gear Box, Solid State Relay Board, Unique Chain Guide
Chain Finish
Nickel Plated
Number of Load Chains
1
Starts and Stops per Hour
300
Current at Min. Voltage
1.4 A
Brake Type
Electromagnetic
For Outdoor Use
Yes
Headroom
11 19/32 in
Number of Reeves
1
Overload Protection Included
Yes
Resistance Properties
Corrosion Resistant
Fixed Lift Speed
32 fpm
Includes Clutch
Clutch Included
Hoist IP Rating
IP65
Operating Voltage
230V AC

Description

Electric Hoists
