  9. High Purity Gas Regulator, Argon, Helium, Nitrogen, Single Stage, 1/2 in Inlet, 1/2 in Outlet
Harris High Purity Gas Regulator, Argon, Helium, Nitrogen, Single Stage, 1/2 in Inlet, 1/2 in Outlet KH1122 - main

High Purity Gas Regulator, Argon, Helium, Nitrogen, Single Stage, 1/2 in Inlet, 1/2 in Outlet

  • Mfr # KH1122

  • Zoro # G7025907

product price: $574.99
/ea
Free Shipping & Returns

Key Features

Compatible Gas Type
Argon, Helium, Nitrogen
Outlet Connection Size
1/2 in
Body Material
Chrome Plated Brass
Number of Stages
Single Stage
Outlet Pressure (Maximum)
500 psig
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KH1122
Zoro #
G7025907
UPC #
725636316195
Country of Origin
United States

Dimensions

Outlet Connection Size
1/2 in
Gauge Diameter
2 1/2 in
Inlet Connection Size
1/2 in
Overall Length
5-1/2"
Overall Width
3.22 in
Body Diameter
2.75 in
Overall Height
6.26 in
Overall Depth
5.54 in
Dedupe with CGA Number and Inlet Connection Size
1/2 in NPT F

Details

Item
High Purity Gas Regulator
Compatible Gas Type
Argon, Helium, Nitrogen
Body Material
Chrome Plated Brass
Number of Stages
Single Stage
Outlet Pressure (Maximum)
500 psig
Outlet Pressure (Minimum)
0 psig
Regulator Supply Type
Pipeline
Standards
CGA E-4
Application
Bulk Gas Distribution Systems, Emission Monitoring Systems Gases, High Flow, High Purity Gas Applications, Laser Gas Systems, Non-Corrosive High Flow Gas Applications, Process Analyzer Gases, Research Sample System Gases
Gauges Delivery Pressure
600 psig
Delivery Pressure Range
0 to 500 psi
Regulator Application
High Pressure
Includes
Harris Model 3530 Single Stage Regulator
Delivery
0 to 500 psig
Regulator Capacity
Heavy Duty
Stages
Single Stage
Supply Pressure Gauge
4,000 psi
Diaphragm Material
302 Stainless Steel
Type
Single Stage
Features
Four Port Configuration, One High Pressure and Three Low Pressure, Self Reseating Internal Relief Valve
Regulator Series
HP 3530
Gas Purity Rating
99.999 %
Seal Material
PTFE
Bonnet Material
Brass
Filter Material
Nickel Plated Bronze
Outlet Connection Gender
Female
Inlet Connection Gender
Female
Outlet Connection Type
NPT
Control Type
Knob
Body Finish
Chrome Plated
Helium Leak Integrity Rating
1.00 x 10^-9 cc/sec
Inlet Pressure (Maximum)
3,000 psig
Inlet Connection Type
NPT
Outlet Thread Direction
Right Hand
Seat Material
PTFE
Inlet Thread Direction
Right Hand
Flow Coefficient
0.08

Description

High Purity Gas Regulator, Mounting Type Pipeline, Number of Stages Single Stage, Compatible Gas Type Argon, Helium, Nitrogen, Control Type Knob, Maximum Inlet Pressure 3,000 psig, Inlet Connection Size 1/2 in, Inlet Connection Gender Female, Inlet Connection Type NPT, Inlet Thread Direction Right Hand, Outlet Pressure (Maximum) 500 psig, Outlet Connection Gender Female, Outlet Connection Size 1/2 in, Outlet Connection Type NPT, Outlet Thread Direction Right Hand

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
