Shop HAYWARD FLOW CONTROL

Check Valve, Ball, PVC/FPM, Flanged

  • Mfr # TC1400F

  • Zoro # G3152606

product price:
$
1,128.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
4"
Connection Type
Flanged
Connection
Flanged
Body Material
PVC
Size
4"
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
TC1400F
Zoro #
G3152606
UPC #
610377166645
Country of Origin
United States
Connection Type
Flanged
Connection
Flanged
Body Material
PVC
Max. Temp. - Valves
140 Degrees F
Max. Water Pressure - Valves
150 psi @ 70 Degrees F
Flow - Valves
275 gpm
Max. Steam Pressure - Valves
Not Rated
Cracking Pressure - Check Valves
3.0 psi
Flow
275 gpm
Mechanism and Body Design
Inline True Union
Standards
ASTM D1784
Full Flow - Valves
Yes
Item
Check Valve
Seal Material
FKM
Seal Material - Check Valves
Viton
Body Material - Valves
PVC
Mounting Position
Vertical (Flow Up)
Flow Design
Single
Mounting Orientation - Check Valves
Vertical
Material of Construction
PVC
Max. Pressure
150 psi @ 70 Degrees F
Connection Type - Check Valves
Flange x Flange
Min. Temp. - Valves
40 Degrees F
Cracking Pressure
3 psi
Seat Material - Check Valves
Viton
Application - Valves
Process Piping
Seat Material
FKM
Sub-Category
PVC
Item - Check Valves
Check Valve
Max. Temp.
140 Degrees F
Mounting Orientation
Horizontal, Vertical
Seal
FPM
Type
Control Check
ANSI Flange Class
Class 150
Coefficient of Volume (Cv)
400
Operating Temperature - Minimum
34 Degrees F
NSF Certifications for Food and Drinking Water
NSF 61
Includes Counterweight
No Counterweight
Operating Temperature - Maximum
140 Degrees F
Silent Check
Standard
3-A Standard Compliance
Not Rated
Connection Type - Side 1
Flange
Valve Body Style
Inline
Maximum Pressure - Steam
Not Rated
Check Mechanism
Ball
Vacuum Service Rating
Not Rated
Manufacturer Warranty
3 yr
Check Mechanism Material
PVC
Maximum Pressure - Operating
150 psi
Connection Type - Side 2
Flange
For Media
Water
Valve Series
TC

Description

The HAYWARD FLOW CONTROL TC1400F is a 4 in inline ball check valve for process piping systems handling water. It features a PVC body, a PVC ball check mechanism, and flanged connections on both ends. This single-flow, full-flow valve opens at 3 psi and closes in response to flow conditions and is intended for reverse-flow control in the line.

Key Features:

  • 4 in nominal valve size with 4 in flange x flange connections
  • PVC body and PVC check mechanism
  • Ball check design with inline true union body style
  • Seal and seat materials: FPM/FKM
  • ANSI flange class: Class 150
  • Flow rate: 275 gpm
  • Cv: 400
  • Cracking pressure: 3 psi
  • Maximum operating pressure: 150 psi at 70 degrees F
  • Operating temperature range: 34 degrees F to 140 degrees F
  • Mounting positions: horizontal, vertical, and vertical flow up
  • NSF 61 certified
  • Meets ASTM D1784
