Shop HAYWARD FLOW CONTROL

Check Valve, True Union, Ball, 1-1/2", PP/FPM, Threaded

  • Mfr # TC30150T

  • Zoro # G2296454

product price:
$
297.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
1 1/2"
Connection Type
Threaded
Connection
FNPT
Body Material
Polypropylene
Full Flow - Valves
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
TC30150T
Zoro #
G2296454
UPC #
610377686631
Country of Origin
United States

Dimensions

Pipe Size
1 1/2"
Size
1 1/2"
Length
6-3/4"
Overall Height
4"
Width
4"
Pipe or Tube Size - Check Valves
1 1/2 in
Overall Length
6.75 in
Pipe or Tube Size
1 1/2 in
Connection Size - Side 2
1 1/2 in
Nominal Valve Size
1 1/2 in
Connection Size - Side 1
1 1/2 in
Wire Rope Length
6.75 in

Details

Connection Type
Threaded
Connection
FNPT
Body Material
Polypropylene
Full Flow - Valves
Yes
Item - Check Valves
Check Valve
Seal Material - Check Valves
Viton
Seat Material
FKM
Max. Water Pressure - Valves
235 psi @ 70 Degrees F
Cracking Pressure
3 psi
Flow Design
Single
Mechanism and Body Design
Inline True Union
Seal Material
FKM
Mounting Orientation - Check Valves
Vertical
Max. Temp.
150 Degrees F
Flow
40 GPM
Min. Temp. - Valves
40 Degrees F
Body Material - Valves
Polypropylene
Max. Pressure
150 psi @ 70 Degrees F
Item
Check Valve
Flow - Valves
40.00 gpm
Cracking Pressure - Check Valves
3.000 psi
Material of Construction
polypropylene
Max. Steam Pressure - Valves
Not Rated
Application - Valves
General Purpose, Pumps
Max. Temp. - Valves
250 Degrees F
Mounting Position
Vertical (Flow Up)
Sub-Category
Polypropylene
Seat Material - Check Valves
Viton
Connection Type - Check Valves
FNPT x FNPT
Standards
ASTM D4101
Mounting Orientation
Horizontal, Vertical
Seal
Viton
Type
Control Check
Includes Counterweight
No Counterweight
Connection Gender - Side 2
Female
Coefficient of Volume (Cv)
45
Maximum Pressure - Operating
150 psi
Manufacturer Warranty
3 yr
NSF Certifications for Food and Drinking Water
NSF 61
Maximum Pressure - Steam
Not Rated
Operating Temperature - Minimum
20 Degrees F
Check Mechanism Material
Polypropylene
3-A Standard Compliance
Not Rated
Connection Type - Side 2
NPT
Connection Gender - Side 1
Female
Operating Temperature - Maximum
180 Degrees F
For Media
Water
Connection Type - Side 1
NPT
Vacuum Service Rating
Not Rated
Valve Body Style
Inline
Silent Check
Standard
Check Mechanism
Ball
Valve Series
TC

Description

Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline True Union, Body Material - Valves Polypropylene, Pipe or Tube Size 1 1/2 in, Connection Type FNPT x FNPT, Cracking Pressure 3 psi, Mounting Orientation Vertical, Seal Material Viton, Max. Temp. - Valves 250 Degrees F, Min. Temp. - Valves 40 Degrees F, Max. Water Pressure - Valves 235 psi @ 70 Degrees F, Max. Steam Pressure - Valves Not Rated, Seat Material Viton, Flow - Valves 40 gpm, Full Flow - Valves Yes
