This item is Discontinued.
Hoffman IEC Combo Str, 2.5-4 A, 120V Coil, 1 Enc VS-CE0204SSP1

IEC Combo Str, 2.5-4 A, 120V Coil, 1 Enc (Discontinued)

  • Mfr # VS-CE0204SSP1
  • Zoro # G6669266
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
VS-CE0204SSP1
Zoro #
G6669266
UPC #
-
Country of Origin
United States

Dimensions

Height
15.39 in
Width
7.38 in
Overall Height
15.39 in
Overall Width
7.38 in

Details

Item
IEC Combination Starter
Overload Relay Amp Setting
2.5 to 4A
Coil Volts
120V AC
Amps AC
2.5 to 4
Enclosure NEMA Rating
1
Operator
Push Button
Short Circuit Protection
Circuit Breaker
Trip Class
10
Pilot Light
Yes
Control Transformer
No
Auxiliary Contact Form
1NO/1NC
Operator Function
Start/Stop
Standards
CSA, UL Listed
HP @ 3 Phase - 240V
3/4 hp
Hz
50/60
HP @ 3 Phase - 480V
2 hp
Number of Poles
3
Minimum Overload Relay Current Setting
2.5 A
Horsepower @ Single Phase - 120V AC
1/6 hp
Includes Control Transformer
No
Coil Voltage
120V AC
Number of Terminals
6
Horsepower @ Three Phase - 240V AC
3/4 hp
Horsepower @ Three Phase - 208V AC
1 hp
Phase
Three
Reversing Capability
Non-Reversing
Horsepower @ Three Phase - 600V AC
5 hp
Starter Style
IEC
Maximum Overload Relay Current Setting
4 A
Current AC
4 A
Number of Auxillary Contacts
2
Terminal Connection Type
Screw Terminals
Overload Protection Type
Thermal
NEMA Enclosure Rating
1
Includes Auxiliary Contacts
Yes
Horsepower @ Single Phase - 240V AC
1/3 hp
Horsepower @ Three Phase - 480V AC
2 hp
Frequency
50/60 Hz
Includes Pilot Light
Yes
Auxiliary Contact Module Capacity
2
Maximum Voltage Rating
600V AC

Description

IEC Combination Starter, Coil Voltage 120V AC, Current AC 4 A, Horsepower @ Three Phase - 600V AC 5 hp, Maximum Voltage Rating 600V AC, NEMA Enclosure Rating 1, NEMA Size Not Applicable, Hazardous Location Specification Not Applicable, Starter Style IEC, Reversing Capability Non-Reversing, Auxiliary Contact Form 1NO/1NC, Short Circuit Protection Circuit Breaker, Includes Control Transformer No, Trip Class 10, Horsepower @ Three Phase - 208V AC 1 hp, Control Transformer Voltage Not Applicable
