Hoffman Nonreversing IEC Magnetic Motor Starter, 4X NEMA Rating, 120V AC, 3 Poles, 1NO EA-A0945SSP - main

Nonreversing IEC Magnetic Motor Starter, 4X NEMA Rating, 120V AC, 3 Poles, 1NO

  • Mfr # EA-A0945SSP

  • Zoro # G3735794

product price:  $1,187.99
/ea
Free Shipping & Returns

Key Features

Overload Relay Amp Setting
9.0 to 45.0
Coil Volts
120V AC
Enclosure NEMA Rating
4X
Auxiliary Contact Form
1NO
HP @ 3 Phase - 240V
15 hp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EA-A0945SSP
Zoro #
G3735794
UPC #
190735370308
Country of Origin
United States

Dimensions

Depth
6.43 in
Height
13.86 in
Width
11.1 in
Overall Width
11.1 in
Overall Height
13.86 in
Overall Depth
6.43 in

Details

Item
IEC Magnetic Motor Starter
Overload Relay Amp Setting
9.0 to 45.0
Coil Volts
120V AC
Enclosure NEMA Rating
4X
Auxiliary Contact Form
1NO
HP @ 3 Phase - 240V
15 hp
HP @ 3 Phase - 575V
40 hp
HP @ 3 Phase - 208V
10 hp
Action
Nonreversing
Amps AC
45.0 A
Number of Poles
3
HP @ 3 Phase - 480V
30 hp
Features
Pilot Light, Start/Stop Push Button
Includes
Bi-metal Overload, Contactor
Standards
CSA, UL 508A
Hz
50/60
Thermal Unit Code
GPS1BH
Includes Auxiliary Contacts
Yes
Hazardous Location Specification
Not Rated
Operator
Push Button
Frequency
50/60 Hz
Maximum Overload Relay Current Setting
45 A
NEMA Enclosure Rating
4X
Trip Class
10
Minimum Overload Relay Current Setting
9 A
Horsepower @ Three Phase - 240V AC
15 hp
Horsepower @ Three Phase - 208V AC
10 hp
Current AC
45 A
Starter Style
IEC
Reversing Capability
Non-Reversing
Mounting Style
DIN Rail, Surface
Overload Protection Type
Thermal
Horsepower @ Three Phase - 600V AC
40 hp
Coil Voltage
120V AC
Phase
Three
Maximum Voltage Rating
600V AC
Operator Function
Start/Stop
Horsepower @ Three Phase - 480V AC
30 hp
Horsepower @ Single Phase - 240V AC
10 hp
Includes Pilot Light
Yes
Number of Auxillary Contacts
1
Horsepower @ Single Phase - 120V AC
5 hp

Description

IEC Magnetic Motor Starter, Includes Auxiliary Contacts Yes, Maximum Overload Relay Current Setting 45 A, Overload Protection Type Thermal, Minimum Overload Relay Current Setting 9 A, Trip Class 10, Number of Poles 3, Number of Auxillary Contacts 1, Phase Three, Operator Push Button, Operator Function Start/Stop, Mounting Style DIN Rail, Surface, Auxiliary Contact Form 1NO, Starter Style IEC, Reversing Capability Non-Reversing, Maximum Voltage Rating 600V AC, Coil Voltage 120V AC
