Carbide Turning Insert, Diamond, CCMT432 / CCMT120408, for Stainless Steel
Mfr # 260221 HBT130
Zoro # G814821799
product price:Â $12.55
/ea
Sold in multiples of 10 for $125.50
Key Features
Chip-Breaker
MM
Insert Thickness
3 mm
Coating
TiCN
Workpiece Material
Stainless Steel
Inscribed Circle
4
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
260221 HBT130
Zoro #
G814821799
UPC #
-
Country of Origin
Korea, Republic of
Dimensions
Insert Thickness
3 mm
Insert Size
432
Corner Radius
0.8 mm
Max. Cutting Depth (ap max)
4.25 mm
Cutting Depth
0.3 mm
Min. Cutting Depth (ap min)
0.55 mm
Details
Item
Indexable Insert for Turning
Chip-Breaker
MM
Coating
TiCN
Workpiece Material
Stainless Steel
Inscribed Circle
4
Insert Material
Carbide
ISO Number
CCMT 120408
Grade
HBT130
Insert Style
CCMT
No. of Edges
2
Insert Shape
80 Degrees Diamond
Cutting Conditions
Slightly Interrupted
Insert Application
Roughing-Finishing
Description
CCMT 120408 HBT130 Grade: HBT130 Chip breaker: MM Cutting depth ap: 0.3 3 mm Feed f: 0.05 0.35 mm/rev. Cutting speed vc main application: 50 200 m/min
