Shop HONEYWELL

2NC Safety Interlock Switch Nema 1, 12, 13 IP 66

  • Mfr # GKEA06L

  • Zoro # G4074612

product price:
$
103.99
/ea
Free Shipping & Returns

Key Features

Style
90 Degrees or Straight Key Actuated, Front and Top Opening, Rotating Head
Series
GKE
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
2NC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GKEA06L
Zoro #
G4074612
UPC #
-
Country of Origin
China

Dimensions

Height
3.61 in
Width
1.2 in
Depth
1.2 in
Conduit Size
1/2 in NPT
Overall Width
1.2 in
Overall Height
3.61 in
Overall Depth
1.3 in

Details

Item
Safety Interlock Switch
Style
90 Degrees or Straight Key Actuated, Front and Top Opening, Rotating Head
Series
GKE
AC Contact Rating
10 A
DC Contact Rating
0.1 to 10 A @ 250 V
Contact Form
2NC
Connection Type
1/2 in NPT Conduit
IP Rating
IP66, IP67
Operating Temp. Range
-13 Degrees to 185 Degrees F
Standards
CCC, CE, cULus, SIL3
Operating Force
5 lb
Description/Special Features
0.5 lb Extraction Force, Enclosure Double Insulated to IEC 536 Class II, Mechanical Life 1,000,000 Operations, Shock 50G per IEC 68-2-27, Vibration 10G per 68-2-6
Contact Material
Silver
Head Material
Thermoplastic
Body Material
Plastic
NEMA Rating
1, 12, 13
Electrical Connection
1/2 in NPT Conduit
Features
Red Switch Body
Actuating Key Type
90 Degrees , Flat
Actuator Material
Stainless Steel
Key Hole Location
Front, Top
Hazardous Location Specification
Not Rated
Includes Actuating Key
No Actuating Key Included
Circuitry Action
Slow Action
Operating Temperature - Minimum
-13 Degrees F
Operating Temperature - Maximum
185 Degrees F
NEMA Enclosure Rating
1, 12, 13, 4, 4X

Description

Safety Interlock Switch, 90 Degrees or Straight Key Actuated, Front and Top Opening, Rotating Head, Contact Form 2NC, Connection Type 1/2 in NPT Conduit, AC Contact Rating 10 A, Series GKE, DC Contact Rating 0.1 to 10 A @ 250 V, Solenoid Voltage Not Applicable, Height 3.61 in, Width 1.2 in, Depth 1.2 in, NEMA Rating 1, 12, 13, IP Rating IP66, IP67, Operating Temp. Range -13 Degrees to 185 Degrees F, Contact Material Silver, Conduit Size 1/2 in NPT, Body Material Plastic
