- MFR #
- BWS1-HL-Y
- Zoro #
- G3943875
- UPC #
- -
- Country of Origin
- Mexico
- Item
- Single-Gas Detector
- Gas Type
- H2S
- Operating Temp. Range
- -40 Degrees to 140 Degrees F
- Alarm Setting
- High 15 ppm, Low 10 ppm
- Detects
- Hydrogen Sulfide
- Standards
ABS Type Approved 21-2143903-PDA, AEx/Ex ia IIC T4 Ga -40 Degrees C Less Than or Equal To Tamb Less Than or Equal To 60 Degrees C, ATEX Sira 18ATEX2243, CSA Certified, CE 2460 Ex II 1G Ex ia IIC T4 Ga, Ex I M1 Ex ia I Ma -40 Degrees C Less Than or Equal To Tamb Less Than or Equal To 60 Degrees C, FCC ID: SU3BWS1, IC:20969-BWS1, IECEX: IECEX SIR 18.0058 Ex ia IIC T4 Ga/Ex ia I Ma -40 Degrees C Less Than or Equal To Tamb Less Than or Equal To 60 Degrees C, INMETRO: DNV 19.0109 Ex ia IIC T4 Ga -40 Degrees C Less Than or Equal To Ta Less Than or Equal To 60 Degrees C, RED:RE-D Directive 2014/53/EU
- Features
- Compatible with Honeywell IntelliDoX, Complete with an Extensive Selection of Sensor Options, Connected Bluetooth Low Energy (BLE) Capabilities Quick Specs, Display for Multiple Languages, Serviceability, User-Friendly Operation
- Interchangeable Sensors
- No
- IP Rating
- IP68
- Resolution
- 0.1 ppm
- Status Indicator
- LED
- Alarm Type
- Audible, Vibrating, Visual
- Housing Color
- Yellow
- Battery Type
- Lithium
- Includes
- Concussion Proof Housing, Stainless Steel Alligator Clip, Test Cap with 1 ft of Hose
- Battery Life
- 1 yr
- Sensor Range
- 0 to 200 ppm
- Power Source
- Battery
- Sensor Life
- 2 yr
- Display
- LCD
- Data Logger
- Yes
- Operating Frequency
- 2402 to 2480 MHz
- Series
- BW Solo
- Resistance Properties
- Dust Resistant, Water Resistant
- Includes Probe
- No
- Replaceable Battery
- Yes
- For Location
- Outdoor
- Hazardous Location Specification
- Class I, Div 1, Group A, B, C, D
- Operating Humidity - Minimum
- 5 %
- Number of Sensors
- 1
- Operating Temperature - Minimum
- -40 Degrees F
- Operating Temperature - Maximum
- 140 Degrees F
- Alarm Setting Adjustment
- Adjustable Alarm Setting
- Chemical Formula
- CIO2, CL2, CO, ETO, H2, H2S, HCN, NH3, NO, NO2, O2, O3, PH3, SO2
- Battery Chemistry
- Lithium
- Alert Type
- Light, Sound, Vibration
- Number of Gases Detected
- 1
- Display Type
- Digital
- Temperature Code
- T4
- Maintainability
- Maintainable
- Alarm Volume Level
- 95 dB
- Mount Type
- Portable/Handheld
- Sensor Type
- Electrochemical
- Visual Alert Type
- Red LED
- Communication Protocol
- Bluetooth
- Compatible Systems and Services
- Android, iOS
- Measurement Range
- Hydrogen Sulfide (0 to 200 ppm)
- Operating Humidity - Maximum
- 95 %
- Rechargeable Battery
- No
- Voltage
- 3.6V
- Operating Voltage
- 3.6V
- Display Screen Type
- LCD Dot Matrix
- Gas Detected
- Ammonia, Carbon Monoxide, Chlorine, Chlorine Dioxide, Ethylene Oxide, Hydrogen, Hydrogen Cyanide, Hydrogen Sulfide, Nitric Oxide, Nitrogen Dioxide, Oxygen, Ozone, Phosphine, Sulfur Dioxide
- Product Type
- Single-Gas Detector
- Sub-Brand
- BW
- Power Source - TS Only
- Battery
- Power Source - old
- Battery
