Honeywell Home DIVERTING VALVE 120/60, 1/2" SWEAT V4044A1019 - main

DIVERTING VALVE 120/60, 1/2" SWEAT

  • Mfr # V4044A1019

  • Zoro # G6403688

product price: $147.99
/ea
Free Shipping & Returns

Key Features

Standards
UL File MH11826
Overall Length
2 3/8 in
Body Material
Brass
Application
Chilled/Hot Water Control
Port Connection Size
1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
V4044A1019
Zoro #
G6403688
UPC #
-
Country of Origin
China

Dimensions

Overall Length
2 3/8 in
Port Connection Size
1/2 in
Overall Depth
4 5/8 in
Overall Width
3 11/16 in
Electrical Lead Length
18 in

Details

Item
Hydronic Zone Valve
Standards
UL File MH11826
Body Material
Brass
Application
Chilled/Hot Water Control
Valve Action
Normally Closed
Actuator Type
Electric
Spring Action
Spring Return
Port Connection Type
Sweat
Close-Off Pressure
20 psi
Actuator Gears Material
Brass
Gasket/Plug Material
Buna-N Rubber (NBR)
Installation Orientation
Horizontal, Vertical
Stem Material
Stainless Steel
Coefficient of Volume (Cv)
4
For Media
Water
Actuator Cover Material
Stainless Steel
Valve Type
Ball
Operating Temperature - Maximum
125 Degrees F
Includes Electrical Leads
Electrical Leads Included
Fluid Temperature - Minimum
40 Degrees F
Actuator Return Action
Spring Return
Actuator Housing Material
Brass
Distance Between Inlet and Outlet Port
3 1/8 in
Body Pattern
Three-Way
Actuator Control Signal
On/Off
Fluid Temperature - Maximum
200 Degrees F
Actuator Voltage
120V AC
Frequency
60 Hz
Includes Actuator
Actuator Included

Description

Hydronic Zone Valve, Actuator Control Pressure - Maximum Not Applicable, Actuator Control Pressure - Minimum Not Applicable, Actuator Control Signal On/Off, Actuator Cover Material Stainless Steel, Actuator Gears Material Brass, Actuator Housing Material Brass, Actuator Return Action Spring Return, Actuator Type Electric, Actuator Voltage 120V AC, Application Chilled/Hot Water Control, Body Material Brass, Body Pattern Three-Way, Close-Off Pressure 20 psi, Coefficient of Volume (Cv) 4
