Actuator - Reversible Gear Motor, 230V, 2.5 Nm, 0-90°, IC20 Series

The HONEYWELL KROMSCHRODER ACT, IC20 30W3TR10 is a reversible gear motor intended for use with gas and air valve actuation. It enables rotary movement between 0 and 90 degrees for valve operation. This model operates at 230V with a frequency range of 50/60 Hz and features a running time: approximately 30 seconds per full 90-degree rotation.

Key features include:

• Reversible gear motor suitable for rotary movement from 0 to 90°
• Compatible with gas and air valve actuation
• Operates on mains voltage: 230V AC, 50/60 Hz
• Running time: approximately 30 seconds per full 90-degree rotation
• Torque output: rated at up to 2.5 Nm (at 50 Hz); maximum rating is up to 3 Nm depending on configuration
• Equipped with voltage-free limit switches, position feedback, externally readable position indicator, and automatic/manual mode changeover
