Air Pressure Switch, DL 10K 4W, -1.5–150 mbar, Adjustable

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 10K 4W is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in systems using air, flue gas, or non-aggressive gases. The device features a switching point adjustment via a setting dial to allow adjustment within the specified operating range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Tube connections: Rp 1/4 and Rp 1/8 (CE versions), 1/4" NPT and 1/8" NPT (UL versions)
• Contact options: Silver contacts (24–250V AC, 0.05–5A CE; 30–240V AC, 5A UL) or gold contacts (5–250V AC, 0.01–5A CE; max 30V AC, 0.05A UL)
• Electrical connection: Screw terminals with M16x1.5 cable gland or screw terminals with a 1/2" NPT cable conduit
• Includes a four-pin plug and socket
• Certified by EU, UL listed, FM approved, AGA approved
• Silicon-free construction
