Air Pressure Switch - DL 50A 62, -1.5 to 150 mbar, UL/CE

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 50A 62 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in systems using air, flue gas, or non-aggressive gases. The device features a switching point adjustment via a setting dial that allows adjustment of the switching point within the specified range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: Tube connections; CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A for CE; 30–240V AC, 5A for UL) and gold contacts (5–250V AC, 0.01–5A for CE; max 30V AC, 0.05A for UL)
• Electrical connection: Screw terminals with M16x1.5 cable gland or optional screw terminals with a 1/2" NPT conduit
• Certifications: EU certified, UL listed, FM approved, AGA approved
• Construction is silicon-free
