Air/Gas Ratio Control Regulator, GIK Series, DN 15–150, 200 mbar Max

The HONEYWELL KROMSCHRODER REG,RTO,GIK 15R02 5B is a pressure regulator rated for air/gas ratio applications; capable of regulating gas/air pressure ratios up to 1:1 under specified conditions. This unit supports both continuous and High/Low/Off control modes depending on the model configuration. It is suitable for use with connection sizes ranging from DN 15 to DN 150 and offers threaded or flanged connection options.

Key features include:

• Capable of regulating gas/air pressure ratios up to 1:1 within the specified operating parameters
• Available in models for continuous (GIK) or High/Low/Off (GIK..B) control
• Nominal diameter range: DN 15 to DN 150
• Connection types: thread or flange
• Maximum rated inlet pressure (pu): 200 mbar
• Rated setpoint adjustment range (psa): 0.5–120 mbar
• Rated outlet pressure differential (pd): 0.2–119 mbar
• Maximum rated differential pressure (Delta p): 100 mbar
