Gas Pressure Regulator & Solenoid Valve, 1-1/2" NPT, 24V DC, IP65

The HONEYWELL KROMSCHRODER VLV, SOLND, PRESS REG, 1 1/2 NPT, VAD2T /40 is a solenoid valve intended for use in applications involving the regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane within specified parameters. It features rapid actuation and includes an integrated pilot lamp for status indication.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Connection size: 1 1/2" NPT
• Electrical connection: M20 cable gland; mains voltage: 24 V DC
• Protection rating: IP65
• Certifications: FM and SA approved; EU certified
• No inlet flange; outlet DN15 (1/2") Rp internal thread
• Accessories include right-side pressure switch (30–110 mbar) with test point and two left-side screw plugs
