Gas Pressure Regulator & Solenoid Valve, 1" NPT, 24V DC, IP65 Rated

The HONEYWELL KROMSCHRODER VLV, SOLND, PRESS REG, 1 NPT, VAD1T /25N/NW is a solenoid valve intended for use in applications involving regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified. It features rapid actuation and is equipped with a pilot lamp that indicates operational status.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Size: 1; Outlet DN 15 (1/2") Rp internal thread
• Electrical connection: M20 cable gland; mains voltage: 24 V DC
• IP65 rated enclosure
• FM and SA approved; EU certified
• No inlet flange; reduced valve seat design
• Accessories include right-side pressure switch (30–110 mbar) with test point and two left-side screw plugs
