Gas Pressure Regulator & Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG1-/25R/NWAE is a gas valve rated for use in gas pressure regulation and control applications within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and features rapid actuation as specified by manufacturer’s operational parameters.

Key features include:

• Integrated pilot lamp for operational status indication
• IP65 rated enclosure
• FM and SA approvals; EU certified
• Outlet: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Outlet pressure range: 35–100 mbar; reduced valve seat design
• Size 1 configuration
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left-side two screw plugs
