Gas Pressure Regulator & Solenoid Valve - 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAG1-/20R/NWAN is a gas valve intended for use in controlling gas pressure within specified parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features rapid actuation mechanism, an integrated pilot lamp, and is rated IP65 according to applicable standards.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage 24 V DC
• Size: 1; no inlet flange included
• Certifications: FM, SA approved; EU certified
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet pressure, left side includes two screw plugs
• Valve seat reduced design
