Gas Pressure Regulator & Solenoid Valve - 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAH1T25N/NQGRAA is a gas valve rated for the regulation and control of gas pressure in industrial or commercial systems. This unit integrates both a Class A pressure regulator (to EN 88) and a Class A solenoid valve (to EN 161), suitable for use with gas, air, and biologically produced methane. It features an integrated pilot lamp for operational status indication and features rapid actuation capability.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage 24 V DC
• IP65 rated enclosure
• FM and SA approved; EU certified
• Size 1 configuration; no inlet flange included
• Valve seat reduced type; right-side accessories include a pressure switch (30–110 mbar) with test point at outlet, left side includes two screw plugs
