Gas Pressure Regulator & Solenoid Valve, 20mm, 24V DC, IP65 Rated

The HONEYWELL KROMSCHRODER VLV, SOLND, PRESS REG, 20MM RP, VAD1/20R/N is a solenoid valve intended for applications involving the regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features rapid actuation and includes an integrated pilot lamp for operational status indication.

Key features:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage: 24 V DC
• Protection rating: IP65
• Certifications: FM and SA approved; EU certified
• No inlet flange; size designation "Size 1"
• Includes right-side accessories such as a pressure switch (30–110 mbar) with test point; left side has two screw plugs
