Gas Pressure Regulator & Solenoid Valve - 3/4" NPT, 24V DC, IP65

The HONEYWELL KROMSCHRODER VLV, SOLND, RTO REG, 3/4 NPT, VAG1T /20N/NQ is a solenoid valve intended for use in applications involving gas pressure regulation and control. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features rapid actuation and includes an integrated pilot lamp for status indication.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage: 24 V DC
• Protection rating: IP65
• FM and SA approved; EU certified
• Valve size: Size 1; reduced valve seat
• Outlet connection: DN15 (1/2") Rp internal thread; no inlet flange
• Accessories include right-side pressure switch (30–110 mbar) with test point and two left-side screw plugs
