Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65
Mfr # KS88000325
Zoro # G815398757
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD125R/NW 50A is a pressure regulator intended for use in applications requiring control and monitoring of gas pressure within specified parameters. It features a Class A pressure regulator to EN 88 standards and incorporates a Class A solenoid valve to EN 161, suitable for use with gas, air, and biologically produced methane. The unit operates at a maximum inlet pressure of 500 mbar (7 psig) and provides an outlet pressure range between 35–100 mbar. The device includes a pilot lamp for status indication and has an IP65 enclosure rating.
Key features:
- Outlet: DN 15 (1/2") Rp internal thread
- Mains voltage: 24 V DC; electrical connection via M20 cable gland
- Provides rapid actuation as specified by manufacturer’s operational parameters
- FM and SA approved; EU certified
- No inlet flange included
- Valve seat: reduced type
- Accessories include right-side pressure switch (30–110 mbar), test point on the right-hand side, left-side screw plugs (2 pieces)
- Size designation: Size 1
