Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD1T25N/NQ-25A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator to EN 88 standards and a Class A solenoid valve to EN 161. The device features an outlet with DN 15 (1/2'') Rp internal thread and operates within an outlet pressure range of 35–100 mbar. It is equipped with a pilot lamp for status indication and features rapid actuation mechanism.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Protection rating: IP65
• FM and SA approved; EU certified
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on the right side of the connection box
• No inlet flange; reduced valve seat design
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet pressure, left-side two screw plugs
• Size designation: Size 1
