Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65
Mfr # KS88004563
Zoro # G015399868
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD3T50N/NQ-25A is a pressure regulator intended for use in controlling and monitoring gas pressure in industrial systems, per product specifications. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified by manufacturer. It features an outlet connection of DN 15 (1/2" Rp internal thread) and operates at a maximum inlet pressure of 500 mbar (7 psig). The device includes a pilot lamp for status indication and is housed in an IP65-rated enclosure.
Key features:
- Outlet pressure range: 35–100 mbar
- Mains voltage: 24 V DC; electrical connection via M20 cable gland
- Features rapid actuation mechanism as described in technical documentation
- FM and SA approved; EU certified
- Size 1 configuration, no inlet flange
- Valve seat reduced design
- Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side; left side fitted with two screw plugs
