Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD125R/NK-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane within specified parameters. It features an outlet connection of DN 15 (1/2" Rp internal thread) without an inlet flange, supports rapid actuation mechanism, and includes a pilot lamp for status indication.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• IP65 rated enclosure
• FM and SA approved; EU certified
• Size designation: Size 1
• Valve seat: reduced type
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left side equipped with two screw plugs
