Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD125/20R/NW-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an outlet with DN 15 (1/2'') Rp internal thread, operates at mains voltage of 24 V DC, and features rapid actuation.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet pressure range: 35–100 mbar
• IP65 rated enclosure
• FM and SA approved; EU certified
• Equipped with pilot lamp
• Electrical connection via M20 cable gland on right side of connection box
• Valve seat reduced; size 1 configuration
• No inlet flange; two screw plugs as left-side accessories
• Right-side accessory: Pressure switch adjustable from 30–110 mbar with test point for outlet pressure
