Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD350R/NP-25A is a pressure regulator intended for regulation and control of gas pressure in various systems. This unit features an integrated solenoid valve and is compatible with gas, air, and biologically produced methane. Built to meet EN 88 (Class A) standards for pressure regulators and EN 161 (Class A) standards for solenoid valves, it operates within its specified parameters.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Quick opening and closing action
• Mains voltage: 24 V DC; electrical connection via M20 cable gland on right side of connection box
• Pilot lamp included; IP65 rated enclosure
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Right-side accessory port supports a pressure switch (30–110 mbar); left side includes two screw plugs
