Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD240R/NPGR-100A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit combines a Class A pressure regulator to EN 88 standards with a Class A solenoid valve to EN 161, suitable for use with gas, air, and biologically produced methane. It features an integrated pilot lamp with rapid actuation capability.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Outlet connection: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Electrical connection: M20 cable gland; mains voltage 24 V DC
• Protection rating: IP65
• Certifications: FM, SA approved; EU certified
• Size designation: Size 1; no inlet flange included
• Accessories include right-side pressure switch (30–110 mbar) with test point at outlet, left side includes two screw plugs
