Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD120R/NK-50A is a pressure regulator intended for regulation and control of gas pressure within specified system parameters. This unit features an integrated solenoid valve compatible with gas, air, and biologically produced methane as specified. It meets Class A standards according to EN 88 for pressure regulators and EN 161 for solenoid valves. The device operates at a maximum inlet pressure of 500 mbar (7 psig) and features a rapid actuation mechanism.

Key features include:

• Outlet: DN 15 (1/2") Rp internal thread
• Outlet pressure range: 35–100 mbar
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• IP65 rated enclosure
• FM and SA approved; EU certified
• Integrated pilot lamp indicator
• No inlet flange; size 1 configuration
• Valve seat reduced; right-side accessories include a pressure switch (30–110 mbar) with test point, left side includes two screw plugs
