Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65
Mfr # KS88029145
Zoro # G015401929
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD240F/NKSR-100A is a pressure regulator intended for regulation and control of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified by manufacturer guidelines. It features rapid actuation mechanism, an integrated pilot lamp, and electrical connection via M20 cable gland. The device is FM and SA approved, EU certified, has an IP65 rating for ingress protection, and operates at a maximum inlet pressure of 500 mbar (7 psig).
Key features include:
- Outlet: DN 15 (1/2") Rp internal thread
- Outlet pressure range: 35–100 mbar
- Mains voltage: 24 V DC
- Size: 1; no inlet flange
- Valve seat: reduced type
- Accessories include right-side mounted pressure switch (30–110 mbar) with test point on outlet side; left side includes two screw plugs
- Features rapid actuation mechanism (opening/closing)
- Electrical connection via right-mounted M20 cable gland
