Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65
Mfr # KS88030629
Zoro # G415402090
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAD2T40N/NQGR-100A is a pressure regulator intended for use in applications requiring control and regulation of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), compatible with gas, air, and biologically produced methane as specified by manufacturer. It features an outlet with DN 15 (1/2'') Rp internal thread and operates at a maximum inlet pressure of 500 mbar (7 psig). The device includes a pilot lamp for status indication and features quick opening and closing operation.
Key features:
- Outlet pressure range: 35–100 mbar
- Maximum inlet pressure: 500 mbar (7 psig)
- Electrical connection: M20 cable gland, mains voltage 24 V DC
- Protection rating: IP65
- Certifications: FM, SA approved; EU certified
- Size designation: Size 1
- No inlet flange; reduced valve seat design
- Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side; left side has two screw plugs
