Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD240R/NWGR-50A is a pressure regulator intended for regulation and control of gas pressure in compatible systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It features an outlet connection of DN 15 (1/2") Rp internal thread and operates at a maximum inlet pressure of 500 mbar (7 psig). The device includes a pilot lamp for status indication and includes rapid actuation mechanism.

Key features:

• Outlet pressure range: 35–100 mbar
• Maximum inlet pressure: 500 mbar (7 psig)
• Electrical connection: M20 cable gland, mains voltage 24 V DC
• Protection rating: IP65
• Certifications: FM, SA approved; EU certified
• No inlet flange; size 1 configuration
• Valve seat reduced; right-side accessories include a pressure switch (30–110 mbar) with test point on outlet side; left-side accessories include two screw plugs
